RD107 series
Rotary damperFeatures:
- Rotary damper with pinion, module 0,8 with 11 teeth and 3mm height
- Clip mounting (backside)
- Housing ultrasonically welded
- RoHS compliant
| Material: | pinion and rotor: POM |
| base: PA66 GF13 | |
| mug: PA66 | |
| O-Ring: Silicone | |
| liquid: Silicone oil | |
| Colour: | black |
| Torques: | according to 20 U/min. @20°C (see table) |
| Lifetime: | 100'000 cycles (1 cycle = 1x forward 150mm, 1x backwards |
| 150mm without break @200 U/min.) | |
| Operating temperature: | -40 to +90°C |
| RoHS compliant |
Other torques, colours and versions with freewheel available on request.
Price in CHF excl. vat.
| Part | Colour coding | Torque | Quantity | Available | Price | Enquiry |
|---|---|---|---|---|---|---|
| RD107-088-PAS-012 | beige | 0,12 Ncm ±0,07 |
|
|||
| RD107-088-PAS-025 | yellow | 0,25 Ncm ±0,08 |
|
|||
| RD107-088-PAS-030 | green | 0,30 Ncm ±0,10 |
|
|||
| RD107-088-PAS-045 | brown | 0,45 Ncm ±0,12 |
|
|||
| RD107-088-PAS-060 | black | 0,60 Ncm ±0,17 |
|
|||
| RD107-088-PAS-095 | red | 0,95 Ncm ±0,18 |
|
|||
| RD107-088-PAS-110 | grey | 1,10 Ncm ±0,20 |
|
|||
| RD107-088-PAS-120 | blue | 1,20 Ncm ±0,20 |
|
|||
| RD107-088-PAS-150 | pink | 1,50 Ncm ±0,25 |
|
|||
| RD107-088-PAS-220 | orange | 2,20 Ncm ±0,35 |
|
